SIKE electromagnetic flowmeter explosion-proof products
Henan SIKE measurement and control technology co., LTD to develop the product - type explosion-proof electromagnetic flowmeter is made at home and abroad advanced technology research and development of explosion-proof intelligent electromagnetic flowmeter, electromagnetic transducer in both Chinese and English menu kernel USES high-speed central processing unit (CPU), computing speed and high precision, reliable performance measurement. Sensor using non-uniform magnetic field technology and special magnetic circuit structure, magnetic field is stable and reliable, and greatly reduce the volume, timely and effective to reflect the traffic always change, stable measuring water, sewage, slurry, pulp, acid, alkali, salt slurry liquid and food, etc. It is widely used in oil and chemical industry, metallurgy, coal, water conservancy projects, sewage treatment, etc. There are two kinds of electromagnetic flowmeter that our company produces: one body and one size.
Product features:
1.The measuring tube has no pressure and no pressure on the pipe.
2.The results of the measurement are independent of physical parameters such as velocity distribution, fluid pressure, temperature, density and viscosity.
3.There is no need for an additional electrode for the measurement of the air tube.
4.Velocity measurement range: 0.1 to 15m/SEC, with a velocity resolution: 0.5 mm/SEC;
5.Low frequency square wave excitation, excitation frequency: 1/16 working frequency, 1/20 working frequency, 1/25 working frequency.
6.High frequency wave excitation, excitation frequency: 1/2 working frequency (suitable for sizing).
7.The system is used for alternating current high frequency switching power supply and voltage range: 85VAC - 250VAC.
8.Dc 24V switch power supply, voltage application range: 20VDC - 36VDC;
9.The display of high definition backlight LCD displays in Chinese and English (customizable other languages).
10.There are three total integrators in the system, which can be recorded separately: total amount, total inversion, total difference;
11.It can be used for digital communication signals such as RS485, RS232, HART, MODBUS, and PROFIBUS (optional).
12.The electrode and lining material are resistant to corrosion and abrasion resistance, which can be customized by the user's special condition.
13.The impact and vibration of the instrument are good;
14.The digital infrared handheld operating keyboard, all functions of remote non-contact operation converter.
15.The explosion-proof type instrument can be used in the corresponding explosion-proof situation.
